Desciption
It is applicable to feed non viscous material, but not suitable for powder materials with good flow ability. The suitable feeding material: powder, granular or small bulk materials such as coal powder, cement, clinker, limestone, clay, gypsum, slag etc.
Features
- Stable operation and easy to operate.
- Wide application, energy saving and efficient.
- The big bearing capacity, smooth operation.
- simple structure, uniform feeding, reliable usage, if adjust the distance between adjusting sleeve and disc, can achieve the purpose of regulating feeding capacity.
Parameter
| Type | Model | Disc diameter (mm) |
Disk speed (r/min) |
Max feed size (mm) |
Feeding capacity (t/h) |
Motor Model | Motor Power (kw) |
Weight (kg) |
|---|---|---|---|---|---|---|---|---|
| Closed hanging | YG300 | 300 | 10.0 | 20 | 0-1.8 | Y80L-4 | 0.55 | 115 |
| YG400 | 400 | 10.7 | 20 | 0-2.6 | Y90L-6 | 1.1 | 120 | |
| YG500 | 500 | 10.7 | 20 | 0-3.3 | Y90L-6 | 1.1 | 124 | |
| YG600 | 600 | 10.0 | 20 | 0-5.0 | Y90L-6 | 1.1 | 130 | |
| YG800 | 800 | 9.0 | 30 | 0-8.0 | Y80L-4 | 0.55 | 195 | |
| YG1000 | 1000 | 9.0 | 30 | 0-12 | Y90L-4 | 1.5 | 263 | |
| YG1500 | 1500 | 7.0 | 40 | 0-22 | Y132M2-6 | 5.5 | 755 | |
| YG2000 | 2000 | 5.0 | 50 | 0-80 | Y160L-6 | 11 | 2517 | |
| Open hanging | DK600 | 600 | 7.53 | 25 | 1.8-3.9 | Y90L-6 | 1.1 | 410 |
| DK800 | 800 | 7.53 | 30 | 3.5-7.6 | Y90L-6 | 1.1 | 600 | |
| DK1000 | 1000 | 7.50 | 40 | 1.8-16.7 | Y100L-6 | 1.5 | 725 | |
| DK1300 | 1300 | 6.50 | 50 | 4.3-27.9 | Y132S-6 | 3 | 846 | |
| DK1600 | 1600 | 6.0 | 60 | 7.03-48.6 | Y132M1-6 | 4 | 1980 | |
| DK1800 | 1800 | 5.0 | 70 | 9.26-60 | Y132M2-6 | 5.5 | 3070 | |
| DK2000 | 2000 | 5.0 | 80 | 13.6-88.4 | Y132M3-6 | 5.5 | 3260 |
