1500 TPD Lead-Zinc Plant in Mexico
Project profile
- Raw material：Copper lead zinc
- Capacity：1500t/d
- Main Equipment：Vibrating Screen, Ball Mill, Spiral Chute, Vibrating Classifier, High Gradient Magnetic Separator.
- Location：Mexico
Project Details
Background
The project ore carbonate rock type deposit, the main metal minerals are galena, sphalerite. Gangue mineral is diopside. The raw ore grade is 5.61g/t.
Process
Beneficiation process
Two-stage and closed-circuit crushing - one-stage self-grinding, regrinding of lead coarse concentrate - preferential flotation - two-stage dehydration process.
Sorting stage
After grinding, lead concentrate with recovery rate of 90.49% can be obtained by one roughing, three sweeping and three cleaning.
Dewatering stage
A disk vacuum filter was used to dehydrate concentrate, and the dewatering rate was over 95%.
Two-stage and closed-circuit crushing - one-stage self-grinding, regrinding of lead coarse concentrate - preferential flotation - two-stage dehydration process.
Sorting stage
After grinding, lead concentrate with recovery rate of 90.49% can be obtained by one roughing, three sweeping and three cleaning.
Dewatering stage
A disk vacuum filter was used to dehydrate concentrate, and the dewatering rate was over 95%.
Feedback
The raw ore grade of the project is 5.61g/t, the lead concentrate grade is 78.85g/t, the flotation recovery rate is up to 90.49%, and the final recovery rate is 90.49%
