Desciption
Dewatering screen is mainly used for dewatering, desliming and demineralization. Therefore, it is also called sand dewatering screen, mining dewatering screen, slime dewatering screen, tailings dewatering screen, high frequency dewatering screen, etc.
Features
- 1.Portable or skid-mounted structures.
- 2.Capacities up to 440 STPH (360 MTPH).
- 3.Total screening area up to 137 square feet (12.7 square meters).
Parameter
| Model | Screen Area (㎡) |
Screen Material | Power (kw) |
Feeding Size (mm) |
Production Capacity (t/h) |
Dimensions (m) |
|---|---|---|---|---|---|---|
| TS0820 | 1.6 | Polyurethane | 0.75×2 | ≤10 | 5-10 | 2.3×1.1×0.8 |
| TS1020 | 2 | 1.1×2 | ≤20 | 15-30 | 2.3×1.5×0.8 | |
| TS1225 | 3 | 2.2×2 | ≤20 | 40-60 | 2.8×1.6×1.0 | |
| TS1530 | 4.5 | 3.0×2 | ≤20 | 60-100 | 3.5×2.0×1.2 | |
| TS1836 | 6.48 | 3.7×2 | ≤20 | 80-150 | 4.0×2.4×2.3 | |
| TS1845 | 8.1 | 11×2 | ≤20 | 100-180 | 5.1×2.4×2.3 | |
| TS2050 | 10 | 15×2 | ≤20 | 150-220 | 5.6×2.6×2.4 | |
| TS2060 | 12 | 15×2 | ≤20 | 200-260 | 6.6×2.6×2.4 | |
| TS2260 | 13.2 | 18.5×2 | ≤20 | 220-300 | 6.6×2.8×2.4 | |
| TS2460 | 14.4 | 18.5×2 | ≤20 | 250-350 | 6.6×3.0×2.5 |
