Desciption
The ball mill machine is known as a ball grinding machine. It is a well-known ore grinding machine and is widely used in mining, construction, and aggregate application. Hongji can supply globally service includes flow design, manufacturing, installation, and free operation training in mining, grinding, screening, crushing plant.
Features
- The transmission machinery of Energy-saving ball mill substitutes large-scale double row self-aligning roller bearing for sliding bearing. It is easy to start and saves energy up to 20-30%.
- Energy-saving ball mill adopts groove-type circular lining plate that is instrumental in increasing contact areas of iron balls and ores, which enhances grinding action and ore lifting capacity and decreases energy consumption.
- Energy-saving ball mill adopts whole milling house, which makes it easy for construction and installation.
- Energy-saving ball mill has bigger discharge opening and huge processing capacity.
- Energy-saving ball mill is equipped with oil-mist lubrication device which guarantees smooth operation of gears.
Parameter
| Model | Cylinder Speed (r/min) |
Balls Load (t) |
Feeding Size (mm) |
Discharge Size (mm) |
Capacity (t/h) |
Motor Power (kw) |
Weight (t) |
|---|---|---|---|---|---|---|---|
| Φ900×1800 | 36 | 1.5 | ≤20 | 0.075-0.89 | 0.65-2 | 18.5 | 4.6 |
| Φ900×3000 | 36 | 2.7 | ≤20 | 0.075-0.89 | 1.1-3.5 | 22 | 5.6 |
| Φ1200×2400 | 36 | 3 | ≤25 | 0.075-0.6 | 2.2-4.8 | 30 | 10.5 |
| Φ1200×3000 | 36 | 3.5 | ≤25 | 0.074-0.4 | 2.7-5 | 37 | 11.8 |
| Φ1200×4500 | 32.4 | 5 | ≤25 | 0.074-0.4 | 4-7.5 | 55 | 13.8 |
| Φ1500×3000 | 29.7 | 7.5 | ≤25 | 0.074-0.4 | 4.3-8 | 75 | 15 |
| Φ1500×3500 | 29.7 | 7.5 | ≤25 | 0.074-0.4 | 4.5-9 | 75 | 16.5 |
| Φ1500×4500 | 27 | 11 | ≤25 | 0.074-0.4 | 6-12 | 90 | 18 |
| Φ1500×5700 | 28 | 12 | ≤25 | 0.074-0.4 | 7-15 | 130 | 22 |
| Φ1830×3000 | 25.4 | 11 | ≤25 | 0.074-0.4 | 6.5-12 | 130 | 28 |
| Φ1830×3600 | 25.4 | 13 | ≤25 | 0.074-0.4 | 8-13 | 130 | 30 |
| Φ1830×4500 | 25.4 | 15 | ≤25 | 0.074-0.4 | 10-18 | 155 | 32 |
| Φ1830×6500 | 24.1 | 21 | ≤25 | 0.074-0.4 | 14-26 | 210 | 35 |
| Φ1830×7000 | 25 | 23 | ≤25 | 0.074-0.4 | 15-28 | 245 | 39 |
| Φ2100×3000 | 23.7 | 15 | ≤25 | 0.074-0.4 | 9-16 | 180 | 37 |
| Φ2100×3600 | 23.7 | 18 | ≤25 | 0.074-0.4 | 10-19 | 210 | 39 |
| Φ2100×4500 | 23.7 | 24 | ≤25 | 0.074-0.4 | 13-24 | 245 | 41 |
| Φ2100×7000 | 23.7 | 26 | ≤25 | 0.074-0.4 | 20-37 | 280 | 55 |
| Φ2200×4500 | 21.5 | 27 | ≤25 | 0.074-0.4 | 14-26 | 280 | 50 |
| Φ2200×7000 | 21.7 | 35 | ≤25 | 0.074-0.4 | 22-41 | 380 | 60 |
| Φ2400×3600 | 21 | 23 | ≤25 | 0.074-0.4 | 14-25 | 320 | 63 |
| Φ2400×4500 | 21 | 27 | ≤25 | 0.074-0.4 | 17-32 | 380 | 69 |
| Φ2400×7000 | 20.9 | 42 | ≤25 | 0.074-0.4 | 26-49 | 480 | 80 |
| Φ2700×3600 | 20.7 | 33 | ≤25 | 0.074-0.4 | 19-32 | 380 | 90 |
| Φ2700×4000 | 20.7 | 35 | ≤25 | 0.074-0.4 | 20-36 | 380 | 94 |
| Φ2700×4500 | 20.7 | 38 | ≤25 | 0.074-0.4 | 21-40 | 480 | 98 |
| Φ2700×7000 | 20.7 | 55 | ≤25 | 0.074-0.4 | 33-62 | 630 | 116 |
| Φ3200×4500 | 19 | 56 | ≤25 | 0.074-0.4 | 35-68 | 800 | 132 |
| Φ3200×7000 | 18 | 73 | ≤25 | 0.074-0.4 | 47-78 | 1250 | 185 |
| Φ3600×4500 | 17 | 76 | ≤25 | 0.074-0.4 | 49-82 | 1250 | 185 |
| Φ3600×6000 | 17 | 100 | ≤25 | 0.074-0.4 | 52-96 | 1400 | 235 |
| Φ3600×8500 | 17 | 130 | ≤25 | 0.074-0.4 | 70-130 | 1800 | 270 |
| Φ3800×6500 | 16.7 | 121 | ≤25 | 0.074-0.4 | 73-137 | 1800 | 277 |
| Φ3800×8500 | 16.7 | 158 | ≤25 | 0.074-0.4 | 82-143 | 2000 | 305 |
| Φ4000×6000 | 16.7 | 135 | ≤25 | 0.074-0.4 | 90-160 | 2000 | 315 |
