Desciption
We manufacture a complete range of Shaking tables to suit all requirements from small laboratory models through to the large process models. Feed capacities can be accommodated from 25 kg per hour to 5,700 kg per hour and can accommodate a wide range of particle sizes.
Features
- The large range of transverse slope adjustment（0～10°），adjustable stroke
- Keep the stably operation when change the transverse slope and stroke
- Spring is arranged in the case with compact structure
- Without reagents consumption, little electricity consumption
Parameter
| Model | Coarse Sand Table | Fine Sand Table | Slime Table | |
|---|---|---|---|---|
| Table Dimension | Length(mm) | 4450 | 4450 | 4450 |
| Gearing Side Width(mm) | 1855 | 1855 | 1855 | |
| Concentrate Side Width(mm) | 1546 | 1546 | 1546 | |
| Max Feed-In Material Size(mm) | 2 | 0.5 | 0.15 | |
| Feed-In Material Capacity(t/d) | 30-60 | 10-20 | 15-25 | |
| Feed-In Materials Concentration(%) | 25-30 | 20-25 | 15-25 | |
| Stroke(mm) | 16-22 | 11-16 | 8-16 | |
| Frequency(f) | 45-48 | 48-53 | 50-57 | |
| Water For Cleaning Table(t/d) | 80-150 | 30-60 | 10-17 | |
| Transverse Gradient(°) | 2.5-4.5 | 1.5-3.5 | 1-2 | |
| Longitudinal Gradient(%) | 1.4 | 0.92 | — | |
| Table Final Angle(°) | 32-42 | 40 | 42 | |
| Dressing Area(㎡) | 7.6 | 7.6 | 7.6 | |
| Table Length Ratio | 2.6 | 2.6 | 2.6 | |
| Bed End Shapes | Rectangle | Sawtooth | Triangular | |
| Power(kw) | 1.1 | 1.1 | 1.1 | |
| Transmission Mechanism | Eccentric Link Mechanism | |||
