Desciption
As a lot of minerals are magnetic to some degree and others are associated with minerals that are ferromagnetic or paramagnetic, high gradient magnetic separator can often be used in separation where normally difficulties are experienced with other processes.
Features
- 1.Low voltage, high current and low current density. Internal water cooling and double circulation cooling mode stable magnetic field. Equipment operation rate is up to 98%;
- 2.Optimized magnetic system design, optimal arrangement and combination of magnetic matrix, background field intensity up to 1.8T. vertical rotation, reverse flushing achieve magnetic matrix is not easy to block;
- 3.Pulsation mechanism design could improve the separation efficiency;Wide separation range: upper limit:6mm, lower limit :2~10μm;
- 17 series of products with more than 70 specifications and models, and capacity of a single unit is from 0.01 to 480t/h;
- Equipped with coil pipeline cleaning system, easy for coil daily maintenance. coil designed life is up to 20 years.
Parameter
| Model | Feeding Size (less than) (mm) |
Feeding Concentration (%) |
Throughput Of Pulp (m³·h-1) |
Dry Ore Capacity (t·h-1) |
Rated Background Magnetic Field Strength (T) |
Rated Excitation Power (kw) |
Pulsating Stroke (mm) |
Pulsation (r·min-1) |
Machine |
|---|---|---|---|---|---|---|---|---|---|
| SLon-500 Strong Magnetic Separators |
1.0 | 10-40 | 0.5-1.0 | 0.05-0.25 | 1.3-1.65 | 13.5 | 0-50 | 0-400 | 1.5 |
| SLon-750 Strong Magnetic Separators |
1.0 | 10-40 | 0.1-2.0 | 0.1-0.5 | 1.3-1.65 | 22 | 0-50 | 0-400 | 3 |
| SLon-1000 Strong Magnetic Separators |
1.3 | 10-40 | 12.5-20 | 4-7 | 1.3-1.65 | 28.6 | 0-30 | 0-300 | 6 |
| SLon-1250 Strong Magnetic Separators |
1.3 | 10-40 | 20-50 | 10-18 | 1.3-1.65 | 35 | 0-20 | 0-300 | 14 |
| SLon-1500 Strong Magnetic Separators |
1.3 | 10-40 | 50-100 | 20-30 | 1.3-1.65 | 44 | 0-30 | 0-300 | 20 |
| SLon-1750 Strong Magnetic Separators |
1.3 | 10-40 | 75-150 | 30-50 | 1.3-1.65 | 62 | 0-30 | 0-300 | 35 |
| SLon-2000 Strong Magnetic Separators |
1.3 | 10-40 | 100-200 | 50-80 | 1.3-1.65 | 74 | 0-30 | 0-300 | 50 |
| SLon-2500 Strong Magnetic Separators |
1.3 | 10-40 | 200-400 | 100-150 | 1.3-1.65 | 94 | 0-30 | 0-300 | 105 |
| SLon-1500 Middle Magnetic Separators |
1.3 | 10-40 | 75-150 | 30-50 | 0.6-1.0 | 16 | 0-30 | 0-300 | 15 |
| SLon-1750 Middle Magnetic Separators |
1.3 | 10-40 | 75-150 | 30-50 | 0.6-1.0 | 38 | 0-30 | 0-300 | 35 |
| SLon-2000 Middle Magnelic Separators |
1.3 | 10-40 | 100-200 | 50-80 | 0.6-1.0 | 42 | 0-30 | 0-300 | 40 |
| SLon-2500 Middle Magnetic Separators |
1.3 | 10-40 | 180-450 | 80-150 | 0.6-1.0 | 63 | 0-30 | 0-300 | 60 |
