Rod Mill

The Rod Mill is the same as the Ball Mill in the construction and available to both of wet and dry processing. Unlike the Ball Mill, however, the Rod Mill uses rods instead of balls as the grinding medium. As a result, its uses are different from those with the Ball Mill. In other words, the Rod Mill gives impact on and grinds coarse particles present between each rod, while no fine particles receive impact and are ground. Therefore, the Rod Mill causes no excessive grinding, enabling you to produce pr...

Material:

Iron ore, copper ore, pyrrhotite, quartz stone, gold ore, and other materials.

Desciption

It is suitable for wet fine crushing and rough grinding of various hardness ores and other materials, especially for adjusting the fineness modulus in the process of artificial sand making.

Features

1.Iron rods can move inside mill with regularity. The curvature of end cover of rod mill is relatively small, which renders iron rods move inside mill with regularity.
2.Easy installation and maintenance.
3.Quick discharging. The diameter of discharge hollow shaft is comparatively bigger, which makes overhaul easier and diminishes, Consequently, discharge becomes faster.
4.Uniform ore particles.
5.Low incidence of overly grinding. Uniform ore particles. Less incidence of overly grinding.

Parameter

Model	Cylinder Specifications (mm)		Cylinder Speed (r/min)	Rod Quantity (t)	Feed Particle Size (mm)	Discharge Particle Size (mm)	Capacity (t/h)	Motor Power (kw)	Weight (t)
Model	Diameter	Length	Cylinder Speed (r/min)	Rod Quantity (t)	Feed Particle Size (mm)	Discharge Particle Size (mm)	Capacity (t/h)	Motor Power (kw)	Weight (t)
MB0918	900	1800	29-31.3	2.3	≤25	0.16-5	1.6-6	22	4.8
MB0924	900	2400	29-35.4	3.1	≤25	0.16-5	2.9-10	30	5.3
MB1224	1200	2400	27-34	6.5	≤25	0.16-5	5.0-13	37	11.8
MB1530	1500	3000	26.5-29.5	11.5	≤25	0.16-5	6.0-25	75	17.2
MB1545	1500	4500	26.5-29.5	14	≤25	0.16-5	10-35	90	22
MB1830	1800	3000	21.6-22.8	17.5	≤25	0.16-5	12-40	155	29.5
MB1855	1800	5500	21.6-22.8	23	≤25	0.16-5	12-60	185	33
MB2130	2100	3000	19-21	23.2	≤25	0.16-5	20-80	210	37
MB2155	2100	5500	19-21	26	≤25	0.16-5	25-100	280	45
MB2430	2400	3000	18-20	32	≤25	0.16-5	30-130	280	60
MB2455	2400	5500	18-20	46	≤25	0.16-5	50-180	380	79
MB2755	2700	5500	17.2-18.5	51	≤25	0.16-5	80-250	560	112
MB3055	3000	5500	17-18	62	≤25	0.16-5	120-300	630	123
MB3255	3200	5500	16.5-18	70	≤25	0.16-5	150-380	800	138
MB3660	3600	6000	16-18	93	≤25	0.16-5	200-580	1600	210

Service Support

We offer free testing services for raw ore materials
Provide you a solution based on your needs.
Test run the machine 48 hours before delivery.
We will send enaineers to quide customers to install and debug the equipment to ensure the normal operation of the equipment.
If the equipment fails, we will send engineers to help you troubleshoot and repair it
